filebeat+kafka+logstash对日志进行统一归集管理

rpm --import https://artifacts.elastic.co/GPG-KEY-elasticsearch

cat > /etc/yum.repos.d/elasticsearch.repo << EOF
[elasticsearch-7.x]
name=Elasticsearch repository for 7.x packages
baseurl=https://artifacts.elastic.co/packages/7.x/yum
gpgcheck=1
gpgkey=https://artifacts.elastic.co/GPG-KEY-elasticsearch
enabled=1
autorefresh=1
type=rpm-md
EOF

yum -y install java-1.8.0-openjdk java-1.8.0-openjdk-devel -y

yum install filebeat -y

cat /etc/filebeat/filebeat.yml
filebeat.inputs:
- type: log
  enabled: true
  paths:
    - /var/log/nginx/access.log
    - /var/log/*.log

filebeat.config.modules:
  path: ${path.config}/modules.d/*.yml
  reload.enabled: false

setup.template.settings:
  index.number_of_shards: 1

processors:
  - add_host_metadata:
      when.not.contains.tags: forwarded
  - add_cloud_metadata: ~
  - add_docker_metadata: ~
  - add_kubernetes_metadata: ~

tags: ["test1"]
output.kafka:
  hosts: ["192.168.162.111:9092"]
  topic: "get_logs"
  required_acks: 1
  compression: gzip
  max_message_bytes: 1000000

yum install logstash -y

mkdir /data/logs/
chown -R logstash:logstash /data/logs

cat /etc/logstash/conf.d/nginx.conf
input {
  kafka {
    bootstrap_servers => "192.168.162.111:9092"
    group_id => "test"
    client_id => "test"
    auto_offset_reset => "latest"
    topics => ["get_logs"]
    codec => json { charset => "UTF-8" }
  }
}

filter {
  ruby {
    code => 'event.set("filename",event.get("[log][file][path]").split("/")[-1])'
  }
}

output {
  # 调试
  stdout { codec => rubydebug }
  if "nginx" in [log][file][path] and "access" in [log][file][path] {
    file {
      path => "/data/logs/live-test-nginx/live-test_%{+YYYYMMdd}_%{filename}"
      flush_interval => 3
      codec => line { format => "%{[tags][0]} %{message}"}
    }
   # 输出到elasticsearch
    elasticsearch {
      hosts => ["localhost:9200"]
   # 定义索引名称
      index => "%{[tags][0]}-api-%{+YYYY.MM.dd}"
      }
  }

  if "nginx" in [log][file][path] and "error" in [log][file][path] {
    file {
      path => "/data/logs/live-test-nginx/live-test_%{+YYYYMMdd}_%{filename}"
      flush_interval => 3
      codec => line { format => "%{[tags][0]} %{message}"}
    }
  }
}

wget -c -P /tmp "https://downloads.apache.org/kafka/3.6.2/kafka_2.13-3.6.2.tgz"

cd /opt/ ; tar xvf /tmp/kafka_2.13-3.6.2.tgz
mv kafka_2.13-3.6.2 kafka
vim kafka/config/server.properties(只配置下面两行,换成本机内网ip)
listeners=PLAINTEXT://192.168.162.111:9092
advertised.listeners=PLAINTEXT://192.168.162.111:9092

配置kafka systemd管理文件
cat /usr/lib/systemd/system/kafka.service
[Unit]
Description=Kafka server daemon

[Service]
Type=simple
ExecStart=/opt/kafka/bin/kafka-server-start.sh /opt/kafka/config/server.properties
KillMode=process
Restart=on-failure
RestartSec=42s

[Install]
WantedBy=multi-user.target

cat /usr/lib/systemd/system/zkp.service
[Unit]
Description=Zookeeper server daemon

[Service]
Type=simple
ExecStart=/opt/kafka/bin/zookeeper-server-start.sh /opt/kafka/config/zookeeper.properties
KillMode=process
Restart=on-failure
RestartSec=42s

[Install]
WantedBy=multi-user.target

systemctl daemon-reload
systemctl restart zkp kafka logstash
systemctl enable zkp kafka logstash
